Features -
19 inchesyes
Number of DMX channels192
Sustainable productnot specified
Joystickyes
Weight and dimensions including packaging
Weight (incl. packaging)3.0 kg
Dimensions (incl. packaging)57.5 x 19.5 x 13.0 cm

Specifications -
practical DMX controller
192 channels
12 fixtures with 16 channels each
memory capacity: 240 scenes over 30 banks
8 scenes per bank, easy to recall with the scene-buttons
8 faders that allow you to customise the values of fixtures (1-8 and 9-16 selection via A/B joy stick)
practical joy stick for correcting pan and tilt movements
optimised for moving heads, scanners, lighting effects and other intelligent forms of DMX lighting
6 programmable chases that can be accesses directly via chase buttons
easy to set up
music controlled mode via line-in signal from a mixer (RCA)
adjustable speed via speed and fade time fader
tap sync function to allow manual tapping along to the beat of the music
DMX output via 3-pole XLR
file dump data-exchange via 3-pole male and female connector (shared with DMX-output)
soft-patch option that allows you to bundle specific channels together on to one fader
MIDI-support for triggering by external MIDI gear
channel inversion possible for mirroring moving heads or scanners
informative display for display of values
blackout button that sets all values to 0
fine-button, to set 16-bits pan and tilt values precisely
DMX polarity switch
operating voltage: 9-12V DC, minimum 500mA
mains voltage: 230V AC, 50Hz
delivered with USB LED lamp and current adaptor
can be built in to 19 inch rack, 3 U
dimensions: 482 x 133 x 80 mm
weight: 2.8 kg

Replacement Value of £160 if lost or damaged.
